Carton Box Making Machine BM2508-Plus

BM2508-Plus carton box making machine is a multifunctional packaging machine with horizontal slotting and scoring, vertical slitting and creasing, horizontal trimming.

Compared with traditional packaging equipment, it has a flexible dimension adjusting system. All settings can be entered directly through a touch screen panel within one minute.

Carton Box Making Machine BM2508-Plus

Carton Box Making Machine Application

BM2508-Plus is a fully automatic carton box making machine, suitable for box plants with small quantity orders and big size cartons, which effectively solves the problem of scattered orders.

It can also provide on-demand corrugated packaging solutions for box factories, furniture, hardware accessories, e-commerce logistics, and other industries. Customized packaging solutions can be designed and provided according to customers’ special requirements.

Standard Configuration

Carton Box Making Machine BM2508 Plus Workflow

Carton Box Making Machine BM2508

Major Functions Of Carton Box Machine BM2508 Plus

Cardboard feeding

Cardboard Feeding

  • 20-50 sheets can be loaded, thickness ranging from 10 to 2 mm.
  • A continuous cardboard feeding system with a vacuum pump makes cardboard feeding more accurate.

Horizontal Slotting & Scoring

  • Two 500mm symmetrical slotting knives
  • Slotting knife and creasing beam integrated design
Vertical Scoring Slitting

Vertical Scoring & Slitting

  • 4 Cutting knives,  rotated by the servo motor to make the side of the carton box  more beautiful and flat
  • 4 Scoring/Creasing wheels
Cross cutting system

Cross Cutting System

  • Cut off excess cardboard without an additional paper separator
Die cutting system

Die Cutting System

  • Hand hole, vent hole, special-shaped rounded corners.
  • Cheap module and easy replacement.
Inline Gluing System

Inline Gluing System

  • Inline cold gluing auto application, no need for extra gluing machine.
  • Highest efficiency and versatility.

More than 100 box styles for your choice

Carton Box Machine Manufacturer FAQs

Service will be online, we have a full set of manuals, instructions, and guide videos for installation. During Covid, we have guided many customers to get the machine done by themselves. This machine is not complicated, easy to install and put into production within one day. There is also online training for your operators.

Yes, our BM2508 Plus machine can provide an optional hand hole punching module.

The normal delivery time is 20 days from deposit, if it is a legal holiday, it will be postponed accordingly.

Consumable parts that usually suggested is slitting knife and fiber comb, which needs to be replaced every six months or a year.

We offer one year of warranty from the date of installation.

We have the CE certification, and the third-party inspection company SGS provides inspection services.

Yes, when there is a program update, we will inform our customer of the programming update.
