Cardboard Box Making Machine BM2508

QINGDAO ANYBOX focuses on corrugated box making slolutions and has developed a series of cardboard box making machines with our patents. All the processes are in our control, which includes the research and development, production, sales, and after-sales service.

We provide packaging solutions for customers who need small quantity box orders quickly with any size box, also we can design the most suitable solution according to customers’ special requirements.

Featured Cardboard Box Machines

Carton Box Machine BM2508Plus

Carton Box Machine BM2508-Plus

Compared with traditional packaging equipment, the BM2508-Plus box making machine is a multifunctional packaging machine, it has a flexible dimension adjusting system. All settings can be entered directly through a touch screen panel within one minute.

Corrugated Box Machine BM2508-SE

Corrugated Box Machine BM2508-SE

BM2508-SE model is an economic version machine, which is of great significance to all users under the epidemic. To reduce budget and expenses, it is equipped with a 900mm lead edge feeder, 2 vertical creasing wheels, and removed handhole die cutting module.

Boxmaker Machine BM3000

Boxmaker Machine BM3000

On the basis of the BM2508-Plus carton box making machine, the Boxmaker BM3000’s maximum cardboard width has been extended to 3 meters, and the production efficiency has increased by 20%. Changeover time is within 40 seconds, quick set up, and easy operation.

Box Making Machine Specification

FunctionBM2508 PlusBM2508 SEBM3000
Corrugated board type Sheets Or Fanfold (Single, Double wall) Sheets (Single, Double wall) Sheets Or Fanfold (Single, Double wall)
Cardboard thickness2-10mm2-10mm2-10mm
Cardboard density range  Up to 1200g/m²  Up to 1200g/m²  Up to 1200g/m²
Max. board size2500mm width x unlimited length2500mm width x unlimited length3000mm width x unlimited length
Min. board size200mm  width x 650mm length200mm  width x 650mm length300mm  width x 650mm length
Production CapacityAppr.7-10 pcs/minuteAppr.7-10 pcs/minuteAppr.8-12 pcs/minute
Depends on size and box style.Depends on size and box style.Depends on size and box style.
Slotting Knife2 pcs *500mm Length2 pcs *500mm Length2 pcs *500mm Length
Vertical Cutting knife444
Scoring/Creasing wheel42  (Option 4)4
Horizontal Cutting knife111
Power supplyBM2508-Plus 380V±10%,Max. 7kW, 50/60 HzBM2508-SE 380V±10%, Max. 6.2kW, 50/60 HzBM3000 380V±10%, Max. 7.7kW, 50/60 Hz
Air Pressure0.6-0.7MPa0.6-0.7MPa0.6-0.7MPa
Dimension3540(W) * 2050(L)* 2090mm(H)3370(W) * 1800(L)* 2000mm(H)3650(W) * 1950(L)* 2090mm(H)
Gross WeightAppr.3300KgAppr.2800KgAppr.3500Kg
Automatic paper feedingLead edge feeder 1400mmLead edge feeder 900mmLead edge feeder 1400mm
Handhole on box sidesHand hole module size (120*120mm)NOHand hole module size (120*120mm)
Air Consumption75L/Min40L/Min75L/Min
Box stylesMore than 60 Fefco codesAbout 27 (36)Fefco codesMore than 60 Fefco codes
All the above specifications are for reference only.
The final interpretation right belongs to Qingdao Anybox On Demand Packaging co., Ltd.

Cardboard Box Machine FAQ

Sorry, our machine doesn’t support this function at present. We recommend that you use a digital or flexographic printer.

Yes, our BM2508 Plus machine can provide an optional hand hole punching module.

We have the CE certification, and the third-party inspection company SGS provides inspection services.

Yes, when there is a program update, we will inform our customers of the programming update.

It is possible but not recommended. The packaging effect of PE film is too poor, and the material will be sticky.

Yes, the most commonly used consumables are slitting knife and fiber comb. We have extra 4 pcs slitting knives and 2 pcs fiber comb with machine shipment. Normally, it’s been enough for one year use.

Our main products include BM2508-Plus, BM2508-SE, BM3000. BM2508-Plus is the best seller, fully automatic with functions of auto feeding, slotting, slitting, creasing, and hand hole die cutting. BM2508-SE is an economic version of Plus, and it removes hand hole die cutting module. BM3000 is our most advantaged box maker. On the basis of the BM2508-Plus machine, its maximum cardboard width has been extended from 2.5 meters to 3 meters, and the production efficiency has increased by 20%.

Want to Buy Cardboard Box Making Machine?

We provide a wide range of cardboard box machines to meet the needs of your business
