Heavy Duty Boxmaker Machine BM3000-HD
Heavy Duty Boxmaker BM3000-HD is a fully automatic box making machine, with multifunctions of auto feeding, slotting, creasing/scoring, slitting, as well as handhole die-cutting. On the basis of the BM2508-Plus machine, its maximum cardboard width has been extended to 3 meters, and the production efficiency has increased by 20%. Changeover time is 1-6 seconds, quick set up and easy operation.
It allows you to get any box in any size within one minute. What you should do is just select pre-programmed box type, enter the material size, box dimensions on the touch screen, then all settings are made automatically in a few seconds through a servo-controlled adjustment mechanism, with no manual settings at all.
Boxmaker Machine Application
With BM3000-HD boxmaker, you get not only an ideal solution for short run box production but also a minimum investment with maximum profits. All of your requirements can be reached with one compact machine, without any other module or equipment.
It is widely used to provide on-demand corrugated packaging solutions for box factories, furniture, hardware accessories, e-commerce logistics, and other industries. Customized packaging solutions can be designed and provided according to customers’ special requirements.
Standard Configuration
- 1 pcs horizontal cutting knife
- 2 pcs slotting knives
- 1 pcs scoring beam
- 4 pcs vertical cutting knives
- 4+4 pcs creasing wheels
- 1 pcs paper feeding bracket
- 1 pcs handle die-cutting module
Boxmaker Machine BM3000-HD Workflow
Major Functions Of Boxmaker Machine BM3000-HD
Cardboard Feeding
- Sheets from E flute to AAA flute
- Sheets thickness from 2mm to 16mm, Up to 2400g/sqm
- Sheets width from 300mm to 3000mm
Horizontal Slotting & Scoring
- Two 500mm symmetrical slotting knives
- Slotting knife and creasing beam integrated design
- Slotting width from 7mm to 15mm
Vertical Creasing System
- Scoring/Creasing wheel : 4+4
- With pre-creasing wheels, the carton box is easy to fold.
Cross Cutting System
- 4 Vertical slitting knives, rotated by the servo motor to make the side of the carton box more beautiful and flat
- Knife sharpening function, the slitting knife has a longer service life
Gluing, Cross Cutting, Glue Flap Crush System
- Inline cold gluing auto application, no need for extra gluing machine.
- Cut off extra cardboard without an additional paper separator.
- The glue flap crash function makes nailing boxes more convenient.
Die Cutting System
- Hand hole, vent hole, special-shaped rounded corners.
- Cheap module and easy to replace.
More than 100 box styles for your choice
Service will be online, we have a full set of manuals, instructions, and guide videos for installation. During Covid, we have guided many customers to get the machine done by themselves. This machine is not complicated, easy to install and put into production within one day. There is also online training for your operators.
Yes, our BM2508 Plus machine can provide an optional hand hole punching module.
The normal delivery time is 20 days from deposit, if it is a legal holiday, it will be postponed accordingly.
Consumable parts that usually suggested is slitting knife and fiber comb, which needs to be replaced every six months or a year.
We offer one year of warranty from the date of installation.
We have the CE certification, and the third-party inspection company SGS provides inspection services.
Yes, when there is a program update, we will inform our customer of the programming update.
