      Corrugated Box Pricing Formula

      Box price (RMB) = Corrugated board price per m² (RMB/m²) × Box expanded area (m²).

      Calculating Corrugated Board Price per m²

      1.1 Standardize Measurement Units

      – Raw material pricing: Purchased facing paper, liner paper, core paper, and corrugated medium are priced per ton (RMB/ton). Convert to RMB/kg (e.g., 5000 RMB/ton = 5 RMB/kg).

      – Grammage: Convert paper weight from g/m² to kg/m² (e.g., 500 g/m² = 0.5 kg/m²).

      – Corrugation compression ratios:

      – A-flute: 1.59 (1.59m of medium → 1m after corrugation)

      – B-flute: 1.36

      – C-flute: 1.50

      – E-flute: 1.27

      1.2 Cost per m² for Each Layer

      – Facing/liner/core paper:

      Example: 350 g/m² facing paper at 5000 RMB/ton:

      `(5000/1000) × (350/1000) = 1.75 RMB/m²`

      – Corrugated medium:

      Example: 180 g/m² medium at 2000 RMB/ton (A-flute):

      `(2000/1000) × (180/1000) × 1.59 = 0.57 RMB/m²`

      1.3 Total Raw Material Cost per m²

      Example: 5-layer board (300 g/m² kraft facing, A/B-flute 180 g/m² medium, 180 g/m² core, 280 g/m² liner):

      Layer Grammage Price (RMB/ton) Calculation Cost (RMB/m²)
      Facing (kraft) 300 5200 (300/1000)×(5200/1000) 1.56
      Medium (A/B) 180 2250 (180/1000)×(2250/1000)×2.95 2.39
      Core 180 1700 (180/1000)×(1700/1000) 0.31
      Liner 280 2500 (280/1000)×(2500/1000) 0.7
      Total       4.96

      1.4 Factory Price of Corrugated Board

      – Factory price = Raw material cost / 0.65 (assuming 65% material cost share).

      Example: `4.96 / 0.65 = 7.63 RMB/m²`.

      Box Expanded Area Calculation

      2.1 Key Parameters

      – Machine width: Typically 1.6m (max 2.2m).

      – Box dimensions: Width (W), Height (H), Length (L) in meters.

      2.2 Formula

      Number of boxes per machine width (Y):

      `Y = Machine width (X) / (W + H + 0.06)` (rounded down).

      1. Pricing width (B): `B = X / Y`.
      2. Pricing length (A): `A = (L + W + 0.06) × 2 + 0.04`.
      3. Box area (S): `S = B × A`.

      Notes:

      – `0.06m`: Edge trimming allowance.

      – `0.04m`: Tongue allowance (non-reducible).
